[admin@media admin]$ ls /usr/local/naclips/conf/
daemon.conf  hosts.allow  hosts.deny  log2db.conf   html5.conf  httpaccess.allow  mime.types  webfilter.conf  xstream.conf  checkspeed.conf
ssl.conf  logfilter.conf  nbalancer.conf

[admin@media admin]$ cat /usr/local/naclips/conf/daemon.conf
; 나클립스 VOD 서버 기본 설정파일 ?  ActiveX / HTML5 / Mobile Player에 모두 적용됨.
; 1.connection port ................................ def : 5660
  C2S_PORT = 5660
; 2.server name .................................... def :
  server_name = Naclips prototype server, NARU
; 3.log file directory ............................. def : logs
  LOG_ROOT  = logs
; 4.receiving timeout .............................. def : 10 (unit : minute) / used in xplayer & extender
  time_out  = 1
; 5.use naclips activex player ..................... def : true
  use_xplayer = true
; 6.use naclips html5 & mobile player .............. def : true
  use_html5_player = true
; 7.set user's connection limit .................... def : 0 (maximum)
  max_connection = 0
; -.access log url ................................. def :
  log_url = http://wwww.nexpoly.co.kr/webface/logface_naclips.php
; -.log child process count ........................ def : false
  log_process_count = no
; -.enable naclips load-balancer ................... def : false
  enable_balancer = no
; -.enable ssl(https) protocol ..................... def : false / ssl.conf 참조.
  enable_ssl = yes
; -.calling point of web-log interface ............. def : 0 (0:befor access, 1:after access, 2:both)
  web_log_point = 2

[admin@media admin]$ cat /usr/local/naclips/conf/xstream.conf
; 나클립스 ActiveX/Plug-in Player를 통한 VOD 스트리밍에 적용되는 설정파일.
; 1.media file root directory ...................... def : media
  MEDIA_ROOT = /media_files
; 2.packet encryption .............................. def : true / 패킷 암호화 여부
  pack_encrypt = true
; 3.client cache option ............................ def : 0 (0:disable 1:temporary 2:permanent) / 클라이언트 암호화 캐싱 설정
  pack_cache = 2
; 4.client cache limit on permanent cache .......... def : 24 (unit : hour) / 캐싱 설정시 캐시파일 유효기간
  pack_cache_limit = 24
; 5.protect script copy & paste .................... def : false (ref- webfilter.conf) / 퍼가기 방지 설정
  protect_paste = true
; 6.user ip filter ................................. def : false (ref- hosts.allow/hosts.deny)
  ip_filter = true
; 7.capture guard(protect media recording) option .. def : 1 (0:disable 1:enable 2:fourcefull) / 동영상 녹화방지 활성여부
  capture_guard = 1
; 8.maximum bandwidth on progressive client cache .. def : 2048(kbps) / 프로그래시브 스트리밍시 최대 전송 속도 지정
  max_kbps = 10240

[admin@media admin]$ cat /usr/local/naclips/conf/html5.conf
; 나클립스 HTML5/Mobile Player를 통한 VOD 스트리밍에 적용되는 설정파일.
; 1.media file root directory ............................ def : media
  MEDIA_ROOT = /vod_media
; 2.turn on custom player mode ........................... def : true(1) / 모바일 어플 플레이어 사용 여부
  use_naclips_player = true
; 3.internal ticket expiration time ...................... def : 5 (unit:second, 0:unlimited)
  inticket_expire = 10
; 4.check browser-agent filter ........................... def : true (ref- conf/agent.filter) / 웹브라우져 ID 필터링 사용 여부
  agent_filter = false
; 5.allowed maximum duplicated same client ip address .... def : 5 / 접속 되는 동일 IP 최대 허용 개수
  maximum_same_ip = 5
; 6.user connection ip filter ............................ def : false (ref- hosts.allow/hosts.deny)
  ip_filter = false
; 7.Whether or not to save client cache file ............. def : true(1) / 웹브라우저 캐싱 활성 여부
;  if 'use_ticketing' is 'true', absolutely 'false' apply to / use_ticketing 항목이 활성화되면 이 항목 값은 무조건 'false'
  client_cache = false
; 8.Expiration date of the client cache files ............ def : 30(unit : days) / 웹브라우저 캐싱 활성시 캐시파일 유효기간
;  allowed when client_cache was 'true'. (if the value is 0, No expiration time) / 0 이면 유효기간 무한대
  cache_exprire = 30
; 9.The maximum number of slice streaming sessions ....... def : 5 (0:not limited)
  maximum_slice = 0
; 0.Initial Buffering Second(s) ......... def : 10 sec / 분량 확보 패킷 초(재생 시작시 지정된 초단위 분량의 패킷을 초고속으로 전송)
  buffering_sec = 30
; 1.streaming command web server tunneling ............... def : false / 스트리밍 명령어, 웹서버 경유 여부
  webserver_tunneling = false
; 2.Capture Guard Enabling ........... 동영상 녹화방지 확장기능 / def : 1 (0.비활성, 1.활성(auto), 2.강제 적용 / naex.filter 참조)
  use_capture_guard = 1
; -.subtitle file root directory ......................... def : / 자막파일(*.srt) 디렉토리
  subtitle_root = /vod_media/subtitles
; -.subtitle-cache file directory ........................ def : subt_cache
  subtitle_cache = /vod_media/subtitles/cache
; -.use encoded_uri mode ................................. def : true(1)  / URL 암호화 사용 여부
  encoded_uri = false
; -.checking streaming speed ............ def : true / 사용자측 기기에서의 인터넷 속도 측정 여부 (측정 옵션은 checkspeed.conf 참조)
  use_check_speed = true
; -.server to client sending time out .................... def : 5 (unit : minute)
  send_timeout  = 5

[admin@media admin]$ cat /usr/local/naclips/conf/httpaccess.allow
method = allow
*
;192.168.0.*
;*.nexpoly.co.kr
;127.0.0.1

[admin@media admin]$ ls /usr/local/nextube/conf/
adminip.conf  daemon.conf  hosts.allow  hosts.deny  html5.conf  mime.types  ssl.conf  webfilter.conf  xstream.conf

[admin@media admin]$ cat /usr/local/nextube/conf/daemon.conf
; 1.connection port .......................... def : 5661
  C2S_PORT = 5661
; 2.server name .............................. def :
  server_name = nextube prototype server, NARU2
; 3.media file root directory ................ def : contents
  FILES_ROOT = /media_files/nextube_data
; 4.log file directory ....................... def : logs
  LOG_ROOT  = logs
; 5.receiving timeout ........................ def : 10 (unit : minute) / used in xplayer
  Time_Out  = 10
; 6.user ip filter ........................... def : false (ref- hosts.allow/hosts.deny)
  ip_user_filter = false
; 7.enable naclips player embeding(CSSP) mode .. def : true / Plug-in Player와 통신여부
  cssp_mode = true
; 8.enable HTTPD mode ........................ def : true  / HTML5, Mobile Player와 통신 여부
  httpd_mode = true
; 9.set user's connection limit .............. def : 0(maximum)  / 최대 동시접속자수 지정.
  max_connection = 0
; -.enable ssl(https) protocol ............... def : false
  enable_ssl = yes
; -.access log url ........................... def :
  log_url = http://wwww.nexpoly.co.kr/webface/logface_nextube.php

[admin@media admin]$ cat /usr/local/nextube/conf/html5.conf
; 1.enable web-browser cache .................. def : true / HTML5 Player에서 브라우져 캐싱 여부.
  client_cache = true
; 2.Expiration date of the client cache files . def : 30(unit : days) / 브라우져 캐싱시 캐시파일 유효 기간.
  cache_expire = 30

[admin@media admin]$ cat /usr/local/nextube/conf/xstream.conf
; 1.protect script copy & paste .............. def : false (ref- webfilter.conf) / 퍼가기 방지 설정
  protect_paste = false
; 2.admin ip filter .......................... def : true (ref- adminip.conf)    / 이미지 파일 삭제 가능한 IP 지정
  ip_admin_filter = false
; 3.title image saving option ................ def : true  / 대표 이미지 저장 활성화 여부
  save_title_image = true
; 4.thumbnail image saving option ............ def : true  / 썸네일 이미지 저장 활성화 여부
  save_thumbnail = true
; 5.automatic thumbnail image saving option .. def : true  / Plug-in Player에서 썸네일 이미지 자동 생성 및 서버로 전송 여부
  auto_thumbnail = true
; 6.enable create sub-directory  ............. def : false / 하위 디렉토리 활성화 여부
  enable_sub_directory = true
; 7.minimum width pixel resized clone image .. def : 480 (0:no resize) / 썸네일 이미지 높이(근사값) 지정.
  resize_minimum_width = 480
; -.user's image capturing option ............ def : false / 사용자가 찍은 영상 스냅샷 서버에 저장 가능 여부
  save_user_image = true
; -.image format of user's image on net ...... def : 0 (0:disable j:jpg p:png) / 사용자 스냅샷 이미지 포맷
  save_user_image_onnet = jpg
; -.user's capture image file directory ...... def :
  FILES_USER = /media_files/nextube_data/user
; -.directory creation user's image on net ... def : false / 사용자 스냅샷 저장시 사용자별 디렉토리 생성 여부
  save_user_image_directory = false

[admin@media admin]$ /usr/local/naclips/daemonctrl start
NACLIPS Daemon Controler for Linux Intel 32/64-Bit Machine. Ver:1.1.200.
Copyright(C) 2015-2017 NEXPOLY Technology Inc, All Rights Reserved.

NACLIPS Daemon for Linux Intel 64-Bit Machine. Ver:2.0.08.
Copyright(C) 2019 NEXPOLY Technology Inc, All Rights Reserved.

.... Reading Main Configuration ....
     10 Configuration(s) fixed up.

.... Reading X-Streaming Configuration ....
     8 Configuration(s) fixed up.

.... Reading HTML5 Streaming Configuration ....
     16 Configuration(s) fixed up.

.... Reading mime type list ....
     15 mime type(s) registered.

.... Reading IP-Filter Configuration ....
     1 allowd host(s) registered.
     1 denied host(s) registered.

.... Reading Denied Spam-log Configuration ....
     3 denied spam-log host(s) registered.

.... Reading SSL Configulation ....
     4 SSL Configulation(s) fixed up.

            Host Server Name : naclips
           Server IP Address : 192.168.1.128
        User Connection Port : 5660
         Naclips Server Name : Naclips prototype server, NARU
                Product Code : 1052
          Maximum Connection : 100
          Connection Timeout : 1 Minute(s)

............................ 중략  ..............................

                   Error Log : /usr/local/naclips/logs/err.log
      X-Player Streaming Log : /usr/local/naclips/logs/acc.log
      HTML5 Media Access Log : /usr/local/naclips/logs/mob.log
         Rovecat Command Log : /usr/local/naclips/logs/rov.log
       Interface URL for Log : http://wwww.nexpoly.co.kr/webface/logface_naclips.php

## Starting up NACLIPS Daemon           .....
## Starting up ServerEngine             ..... OK(pid:17269).

[admin@media admin]$ /usr/local/nextube/daemonctrl start
NEXTUBE Daemon Controler for Linux Intel 32-Bit Machine. Ver:1.1.200.
Copyright(C)2015-2017 NEXPOLY Technology Inc, All Rights Reserved.

NEXTUBE Daemon for Linux Intel 64-Bit Machine. Ver:2.0.00.
Copyright(C)2019 NEXPOLY Technology Inc, All Rights Reserved.

.... Reading Main Configuration ....
     12 Configuration(s) fixed up.

.... Reading HTTP Streaming Configuration ....
     2 Configuration(s) fixed up.

.... Reading mime type list ....
     3 mime type(s) registered.

.... Reading SSL Configulation ....
     4 SSL Configulation(s) fixed up.

            Host Server Name : devel
           Server IP Address : 192.168.1.1
        User Connection Port : 5661
         Nextube Server Name : nextube prototype server, NARU2
                Product Code : 1076
          Maximum Connection : 100
     Contents Root Directory : /media_files/nextube_data
          Connection Timeout : 10 Minute(s)

............................ 중략  ..............................

                   Error Log : /usr/local/nextube/logs/err.log
File Access Log(On CSSP Mode): /usr/local/nextube/logs/p_acc.log
File Access Log(On HTTP Mode): /usr/local/nextube/logs/w_acc.log
       Interface URL for Log : http://wwww.nexpoly.co.kr/webface/logface_nextube.php

## Starting up NEXTUBE Daemon           .....
## Starting up ServerEngine             ..... OK(pid:17331).

[admin@media admin]$ ps aux | grep naclips  <= 1 접속시 프로세스 조회
root    17269  0.0  0.1 13704  564 pts/3    Sl   10:36   0:00 [naclips.d] <= Parent Process
root    17385  0.0  0.1 13760  876 pts/3    Sl   10:49   0:00 [naclips.d] <= Child Process
root    17394  0.0  0.1  4468  576 pts/3    S+   10:50   0:00 grep naclips

[admin@media admin]$ ps aux | grep nextube  <= 1 접속시 프로세스 조회
root    17331  0.0  0.1 12900  556 pts/3    Sl   10:43   0:00 [nextube.d]
root    17383  0.0  0.1 12928  824 pts/3    Sl   10:49   0:00 [nextube.d]
root    17396  0.0  0.1  4344  568 pts/3    S+   10:50   0:00 grep nextube
